Design Standard Series X-Low Glare Downlight Tilt 9.5W 230mA CC IP54 IC-F/IC-4 c/w UID Dimmable Driver 4000K -Black V2

Technical Specification

9.5W Downlight – Dimmable with Flicker-Free Driver (4000K)

• Wattage: 9.5W

• Cut Out: 85-92mm

• Dimensions (Diameter x Height): 100mm x 101mm

• Colour Temperature: 4000K Natural White

• Lumens: 850lm

• CRI: 90

• Lifespan: <60,000hrs (L80)

• Beam Angle: 50°

• Binning: SDCM 3

• Tilt Angle: 32°

• Finish: Black

• Material: Aluminium, PC

• Ingress Protection: IP54

• Classification: IC-F / IC-4

• Side Clearance (SCB): 0mm

• Height Clearance (HCB): 0mm

• Driver: Included

• Dimming / Control: Dimmable

• Driver Output Current: 230mA

• Electrical Class: Class II

• TLAs: "Flicker-free", PstLM =1.0; SVM =0.4

• Features: UID™ Under Insulation Dimmable Driver Included pre-wired

• Warranty: 5 Year Warranty
