Driver CV Pri:240V Sec:12V DC IP67 0-200W
Technical Specification
Product Sheet
Model: DCC16670-IP67-12V-200W
Product Overview
The DCC16670-IP67-12V-200W is a high-performance, non-dimmable LED driver engineered for demanding environments. Designed to deliver a constant 12V output at up to 16.67A, it is ideal for high-power LED applications requiring durability, efficiency, and reliability. With an IP67-rated enclosure, it offers strong protection against dust and moisture, making it suitable for both indoor and outdoor installations.
Specifications
-
Power Range: 0W – 200W
-
Input Voltage: 100–240V AC, 50/60Hz
-
Output Voltage: 12V DC
-
Output Current: 0 – 16.67A
-
Dimming / Control: Non-Dimmable
-
Electrical Class: Class I
-
Ingress Protection: IP67
-
Dimensions: 249 mm (L) x 72 mm (W) x 40 mm (H)
Warranty
Supplied with a 5-year manufacturer’s warranty, covering defects in materials and workmanship under standard operating conditions.
