Driver CV Pri:240V Sec:12V DC IP67 0-200W

Technical Specification

Product Sheet
Model: DCC16670-IP67-12V-200W

Product Overview
The DCC16670-IP67-12V-200W is a robust, non-dimmable LED driver designed for high-output applications in both indoor and outdoor environments. With a stable 12V DC output and high current capacity, this driver is ideal for powering large-scale LED systems. Its IP67-rated housing ensures protection against dust and water, making it suitable for challenging installation conditions.

Technical Specifications

• Power Output: 0W – 200W

• Input Voltage: 100–240V AC, 50/60Hz

• Output Voltage: 12V DC

• Output Current: 0 – 16.67A

• Dimming / Control: Non-Dimmable

• Electrical Class: Class I

• Ingress Protection: IP67

• Dimensions: 249 mm (Length) x 72 mm (Width) x 40 mm (Height)

Warranty
Includes a 5-year warranty, covering defects in materials and workmanship under normal operating conditions.
