Driver CV Pri:240V Sec:24V DC IP67 0-200W
Technical Specification
Product Sheet
Model: DCC8340-IP67-24V-200W
Product Overview
The DCC8340-IP67-24V-200W is a high-capacity, non-dimmable LED driver designed for use in 24V lighting systems. Delivering up to 200W of power with a maximum output current of 8.34A, this unit ensures efficient performance in a wide range of industrial and outdoor applications. Its IP67-rated enclosure provides robust protection against dust and water, while the Class I design supports secure and reliable operation.
Technical Specifications
-
Power Output: 0W – 200W
-
Input Voltage: 100–240V AC, 50/60Hz
-
Output Voltage: 24V DC
-
Output Current: 0 – 8.34A
-
Dimming / Control: Non-Dimmable
-
Electrical Class: Class I
-
Ingress Protection: IP67
-
Dimensions: 191 mm (L) x 58 mm (W) x 32 mm (H)
Warranty
Includes a 5-year warranty, ensuring dependable long-term operation under normal usage conditions.
