Driver CV Pri:240V Sec:24V DC IP67 0-200W

Technical Specification

Product Sheet
Model: DCC8340-IP67-24V-200W

Product Overview
The DCC8340-IP67-24V-200W is a robust, non-dimmable LED driver engineered for high-performance 24V DC lighting systems. With a maximum output power of 200W and current capacity up to 8.34A, this driver is ideal for industrial, commercial, and outdoor applications. The IP67-rated housing provides excellent protection against dust and moisture, ensuring durability and reliability in demanding environments.

Technical Specifications

• Power Output: 0W – 200W

• Input Voltage: 100–240V AC, 50/60Hz

• Output Voltage: 24V DC

• Output Current: 0 – 8.34A

• Dimming / Control: Non-Dimmable

• Electrical Class: Class I

• Ingress Protection: IP67

• Dimensions: 191 mm (Length) x 58 mm (Width) x 32 mm (Height)

Warranty
Backed by a 5-year warranty covering manufacturing defects under normal operating conditions.
