Driver Mini Dim IP65 CC Pri:240V Sec: 7-15V DC 700mA 5-10W

Technical Specification

Product Sheet
Model: DCC700700-PD-IP65-0715W

Technical Specifications

The DCC700700-PD-IP65-0715W is a compact, primary-dimmable LED driver designed for low-power applications. With IP65 protection and high performance in various environments, it ensures safe and stable operation for both residential and commercial use.

• Wattage: 5W – 10W

• Input Voltage: 220–240V AC, 50/60Hz

• Driver Output Current: 700mA

• Driver Output Voltage: 7 – 15V DC

• Dimming / Control: Primary Dimmable

• Electrical Class: Class II

• Ingress Protection: IP65

• Power Factor: 0.90C

• Ambient Operating Temperature: -20°C to +60°C

• Material: Self-extinguishing plastic housing

• Temporal Light Artifacts: Flicker-free (PstLM = 1.0; SVM = 0.4)

Warranty

Includes a 5-year warranty covering manufacturing defects and performance issues under normal operating conditions.
