Driver Mini IP65 CC Pri:240V Sec:2-8V DC 500mA 1-4W

Technical Specification

Product Sheet
Model: DCC500-M-4W-IP

Technical Specifications
This LED driver is designed to deliver consistent, dimmable power for LED lighting systems.

• Wattage: 15W–30W

• Input Voltage: 220–240V AC, 50/60Hz

• Driver Output Current: 500mA

• Driver Output Voltage: 30–60V

• Dimming / Control: Dimmable

• Electrical Class: Class II

• Ingress Protection: IP20

Physical Characteristics

• Length: 166 mm

• Width: 52 mm

• Height: 24 mm

• Material: Self-extinguishing plastic housing

Features

Part of the DX Series, this driver offers high reliability, efficient power regulation, and smooth dimming functionality.

Warranty

Backed by a 5-year warranty, ensuring long-term performance and peace of mind under standard usage conditions.
