Driver Pri Dim CC Pri:240V Sec:28-56V DC 700mA 19.6-40W
Technical Specification
Product Sheet
Model: DCC700700-PD-2856W
Technical Specifications
The DCC700700-PD-2856W is a primary-dimmable LED driver designed for energy-efficient lighting systems. Engineered to deliver stable performance, it supports a broad voltage range and is ideal for indoor applications where dimming functionality is required.
-
Wattage: 19.6W – 40W
-
Input Voltage: 220–240V AC, 50/60Hz
-
Driver Output Current: 700mA
-
Driver Output Voltage: 28 – 56V
-
Dimming / Control: Primary Dimmable
-
Electrical Class: Class II
-
Ingress Protection: IP20
Physical Characteristics
-
Length: 166 mm
-
Width: 52 mm
-
Height: 25 mm
-
Material: Self-extinguishing plastic housing
Warranty
Backed by a 5-year warranty covering manufacturing defects and performance under standard operating conditions.
