Driver Pri Dim CV Pri:240V Sec:24V DC 12-50W
Technical Specification
Product Sheet
Model: DCC2080-IP20-24V-50W
Product Overview
The DCC2080-IP20-24V-50W is a reliable, primary dimmable LED driver engineered for use in 24V lighting systems. Delivering between 12W and 50W of power with an adjustable output current range from 0.5A to 2.08A, this driver is ideal for a wide range of indoor lighting applications. Its IP20-rated enclosure is suited for dry, indoor environments, while the Class II design ensures safe, double-insulated operation.
Technical Specifications
-
Power Output: 12W – 50W
-
Input Voltage: 220–240V AC, 50/60Hz
-
Output Voltage: 24V DC
-
Output Current: 0.5 – 2.08A
-
Dimming / Control: Primary Dimmable
-
Electrical Class: Class II
-
Ingress Protection: IP20
-
Dimensions: 184 mm (Length) x 61 mm (Width) x 32 mm (Height)
Warranty
Backed by a 5-year warranty, ensuring dependable performance over time.
