Driver Pri Dim CV Pri:240V Sec:24V DC 65-200W IP67
Technical Specification
Product Sheet
Model: DCC8300-IP67-24V-200W
Product Overview
The DCC8300-IP67-24V-200W is a high-performance, primary dimmable LED driver designed for demanding 24V lighting applications. With an adjustable output current range of 2.7A to 8.3A and power output from 65W up to 200W, this driver offers both flexibility and efficiency. Its rugged IP67-rated enclosure ensures full protection against dust and water ingress, making it suitable for outdoor and industrial environments. The Class I electrical design guarantees safe and reliable operation.
Technical Specifications
-
Power Output: 65W – 200W
-
Input Voltage: 220–240V AC, 50/60Hz
-
Output Voltage: 24V DC
-
Output Current: 2.7 – 8.3A
-
Dimming / Control: Primary Dimmable
-
Electrical Class: Class I
-
Ingress Protection: IP67
-
Dimensions: 249 mm (Length) x 72 mm (Width) x 40 mm (Height)
Warranty
Covered by a 5-year warranty, ensuring long-term reliability and performance under standard operating conditions.
