Driver Pri Dim CV Pri:240V Sec:24V DC 9.6-25W
Technical Specification
Product Sheet
Model: DCC1040-IP20-24V-25W
Product Overview
The DCC1040-IP20-24V-25W is a compact, primary dimmable LED driver designed for 24V lighting systems. Offering a power range from 9.6W to 25W and an output current of 0.4A to 1.04A, this driver provides efficient and stable performance for a variety of low- to mid-power lighting applications. Its IP20-rated housing is suitable for indoor environments, and the Class II electrical design ensures enhanced safety during operation.
Technical Specifications
-
Power Output: 9.6W – 25W
-
Input Voltage: 220–240V AC, 50/60Hz
-
Output Voltage: 24V DC
-
Output Current: 0.4 – 1.04A
-
Dimming / Control: Primary Dimmable
-
Electrical Class: Class II
-
Ingress Protection: IP20
-
Dimensions: 122 mm (Length) x 52 mm (Width) x 30 mm (Height)
Warranty
Includes a 5-year warranty for peace of mind and dependable long-term operation.
